Reject Sorter

Send us an enquiry
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.

Applications & Salient Features

It is a typical last-stage screen to handle the last-stage coarse screen reject. The reject sorter with a specially designed rotor is fitted with sweeping distributing blades of specially hardened MOC. The rotor impels the stock feed against the screen half, cleans the screen half, and disaggregates the fiber bundle for better sorting.

  • Discharge of raw rejects virtually free from fiber
  • Specially designed rotor with distributing blades and sweeping blades
  • Gravity feed and discharge
  • The turbulence chamber deflakes and separates the fibers
  • Higher fiber recovery and debris removal
  • Screen halves of different sizes and types of hole
  • Significant cost saving in terms of fiber loss

Main Specifications:

RSR MOTOR RPM – 1470
MODEL HRS TPD POWER(kw)
1 6 – 12 22
2 15 – 25 45
