Upflow Pressure Screen
Applications & Unique Features
The screen has its inlet from the bottom side. Accordingly, the light reject is purged from the top side. There are various types of foiled rotors that can be selected based on the application.
- More efficient debris removal
- Better quality of screening
- Heavy debris rejected to junk box in the bottom, Preventing wear and damage to rotor and screen basket
- Rejects remain in the screening zone for lesser time
- Screen baskets designed with smooth counted hide rejected sorter in application
- Light reject debris are removed immediately through the top of the screen via the reject nozzle
Technical Specifications:
| RSR | MOTOR RPM - 1450 | |
|---|---|---|
| MODEL PMS | TPD | POWER(Kw) |
| 3 | 55 | 40 |
| 4 | 75 | 55 |
| 66 | 90 | 140 |
| 8 | 110 | 230 |
Photos:
