Parason SharpEdge Drum Pulper For Effective Fiber Treatment
Parason SharpEdge Drum Pulper follows an effective pulping process for recovered fibers that require careful & gentle pulping to meet the various requirements of the paper industry. Parason SharpEdge Drum Pulper is a machine developed for efficient pulping of stock consistencies up to 15%- 18% and for gentle and effective separation of fibers and contaminants.
Principle Of Parason SharpEdge Drum Pulper
Parason SharpEdge Drum Pulper uses the concept of a washing machine for its working. The HiTech Bar Knives Metallurgy is adopted for the first time in the world. It is a superb combination at a lower cost and reduced power in the Refining process. The pulp & the water are mixed and the concept of the Drum screen is used. The Drum Pulper consists of two zones: SlushingZone and Screening Zone. For writing printing paper, the slushing zone is divided into two parts and the screening zone is one part with one chest. For Kraft paper, the slushing zone is one part, the slushing zone + screening zone is the second part, and the screening zone is the third part. It is supported by two chests.
Technical Specifications:
Installation Size
Production (T/Day)
Installed capacity [kW]
PDP-15
150
132
PDP-30
300
250
PDP-45
450
400
1000
100-130
110
PDP-60
600
560
PDP-80
800
800
PDP-100
1000
1000
Advantages of The Parason SharpEdge Drum Pulper
It comes with a maintenance-free girth gear drive
Elimination of tyres for the drive
It uses the replaceable refiner plate bars with Parason ERP'” for slushing the pulp
Manufacturing up to 1500 TPD of SharpEdge Donn Pulper
Parason SharpEdge Drum Pulper can be used for Writing Printing, News Print, Kraft Paper, Low BF 14, 16,18 BF of paper
Low maintenance cost
SharpEdge Drum Pulper Reject with efficient removal of contaminants and minimum fibre loss
Features Of Newly Modified Design
Standard diameter
At this diameter, the pulp falling stock between 11 O’clock to 11.30 so that the maximum height is achieved
The length of the Parason SharpEdge Drum Pulper varies as per the capacity
Raw material flexibility: Slush highly contaminated recycled paper
Gentle processing: Removal of an easy-to-slush fine fraction as soon as possible
Operation with low net energy consumption between 15-25 kWh/t
Low fiber loss due to non-shredding of contaminants
